Dual Spindle CNC Drilling And Milling Machine For 300-3000mm Length
  • Name
  • Name
  • Name
  • Name

Dual Spindle CNC Drilling And Milling Machine For 300-3000mm Length

MOQ: 1
Price: negotiable
Standard Packaging: Different packaging methods are adopted according to different modes of transport.
Payment Method: Western Union, MoneyGram, T/T
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
H.SON
Highlight:

Dual Spindle cnc drilling and milling machine

,

3000mm cnc drilling and milling machine

,

300mm cnc mill drill

Product Description

Dual-Spindle CNC Milling and Drilling Machine, High Efficiency for 300~3000mm Length



Specifications and Technical Parameters
ltem unit FDX100
Processing dia range mm ∅20~∅100
Processing lenght range mm 300~3000
Milling depth MAX mm 5
Center drill dia range mm A2~B10
Milling spinde speed r/min 300~800
Drilling spinde speed r/min 600~1600
Power of the main motor KW 5.5
Overall dimensions(LxWxH} mm 5900x2100x2100
Machine weight kg 11000
Working Accuracy
Milling length consistency mm ±0.1
Center hole depth consistency mm ≤0.05
Face runout of the Center hole mm <0.05/∅100
Center hole surface roughness Ra 3.2
Optional function parameters
Turning dia MAX mm ∅100
Effective length of the package mm 20~30
Rigid tapping   M24
